Let's talk about water movement in an SPS tank.

OK, with the success of the two other threads, the lighting thread and water quality thread. Lots of people wanted to talk about water movement.

IMO, there are many way to go about creating good water movement in an SPS tank. Many products and methods can be used: Closed loops, power heads, Tunze Streams, wavemakers and spraybars to name a few. The key, IMO, is not to have any dead spots in the tank. Something that becomes progressively more difficult as the tank matures and Acroporids grow into the flow cutting off water flow to areas (and corals) behind them.

I wanted to attach some mov files to show what I mean by current in the tank. All the polyps on the coral should be moving. I think that better water flow allows the polyps to be swirled around rather than all blowing in one direction. With a slight pause once in a while if you have varied current (a good thing). I once read someone explain it by stating the polyps should look like a small bush does if you give it a good shake once in a while.

The first movie shows a coral in my tank near the bottom middle. It gets good flow from both two sea swirls and a Tunze stream. You can see the polyps being to tossed about a good bit in this one.

click to watch movie
MOV file is 5MB


Next is a movie of the underside of a table I have. One of the problems we face in our tank, is that certain areas get less current over them as corals grow. It's important to periodically check the coral, top to bottom, to make sure the coral is getting good water movement around it, especially near the base. Many times a coral gets poor water flow around the base, then after a number of months of this, eventually the acro finally starts to recede from the base. It's a common problem that effects corals as the tank ages. Ensuring good flow around the base can help to eliminate these problems (at least due to water flow)


click to watch movie
MOV file is 5MB


While looking at this you can see the flow is not as intense as the rest of the coral but it still gets a few good blasts of water every few seconds.

That last movie I wanted to show you, as I think one of the biggest problems we have to face is lack of flow in the tank as the corals grow and the tank gets older. Many people start noticing a lot of recession on the base of their Acroporids after a few years. The tank is packed with coral (many large staghorns) and most likely the culprit is poor circulation.

OK those are my opening thoughts. Hopefully the movies are able to help you to see what the polyps should look like when getting good flow.

So let's discuss what works for you, or hasn't, or what questions you might have.


__________________
-Joe

TOTM Sept 2002 | Reefland Featured Member April 2004
CORAL Magazine Oct/Nov Featured Tank 2007 | Featured Tank "Coral Reef Aquarium" 2011

Current Tank Info: 270G SPS Tank, 140G sumps, 35G Frag Tank, Ultra Reef Akula UKS-200 Skimmer, Apex, Giesemann Spectra 3x250W MH 4x80W T5, 2xReefbrite Tech 72" Blue LED, Triton Dosing, ARID C30 Algae Reactor, Maxspect Gyre
JB NY is offline   Reply With Quote
Old 07/15/2004, 09:26 AM   #2
JOSHUAB
Registered Member

JOSHUAB's Avatar

Join Date: Apr 2003
Location: Chandler, Az.
Posts: 523
That's awesome!!!
So basically it's not how much flow, but where the flow is and where it is going, correct????


JOSHUAB is offline   Reply With Quote
Old 07/15/2004, 09:30 AM   #3
schanz
Registered Member

schanz's Avatar

Join Date: Apr 2002
Location: Central Missouri
Posts: 1,000
Good thread. Water flow is the last obstacle I need to takle on my reef. I think we should each start our replies by listing our current circulation methods.

I'm currently running one seio and 3 MJ1200's along with about a 600 gph return (from basement). All powerheads are pointing at another PH. Flow is good and varied through much of the tank but I can't get rid of dead spots.

I've gone over and over strategies and can't think of any that won't cost a fortune. I can tell what a difference flow makes when I move corals around and see the reactions. Policipora seems to be the most affected in my tank with recession around the base. I guess because their so dense.

I'm leaning toward replacing my 3 MJ's with a tunze 6080. I would then have the tunze on one side pointing at the seio on the other. I'm worried about getting whirlpool flow since the tunze will overpower the seio. I will probably end up with two tunze's since seio's don't have enough force to cover 6' of tank.

so how do you guys mount your tunze's? On each end pointing at each other? Is a controller necessary or just nice. My MJ's are creating shade in the middle and I want them out.


__________________
Got Flow?
120 gallon sps, closed loop. Phoenix 14K. SSB, RDSB, Chaeto
schanz is offline   Reply With Quote
Old 07/15/2004, 09:40 AM   #4
Mark
Premium Member

Mark's Avatar

Join Date: Oct 1999
Location: Atlanta, GA, USA
Posts: 4,552
Water flow shouldn't only be addressed by pumps and and other current generators. Two other big factors is live rock aquascaping and stocking densities. Poor rock placement has a huge impact on flow. This is obvious and advised by most reef books. But stocking density is the other big issue. It really doesn't matter how many Tunze streams you have if you try to crowd too many sps-corals together. They will quickly block each other off from incoming current. That is why some more experienced sps keepers get a little critical of densely stocked tanks full of frags and colonies. After having my share of RTN episodes and crashes, I've learned less is more. I think it's much easier to regulate flow in a tank with fewer but much larger colonies, than a tank with many colonies that are smaller and crowded.

Take JB's tank for example: as his coral have grown, he's removed some colonies to make room for the growth of other colonies(reading from other posts). I'm willing to bet that the remaining corals grew faster after the removal, by opening the coral up to more flow and light.


__________________
-Mark

TOTM March 2001

Current Tank Info: 225g stony reef, 38g softie
Mark is offline   Reply With Quote
Old 07/15/2004, 09:43 AM   #5
Carrera07
Premium Member

Carrera07's Avatar

Join Date: Jul 2003
Location: SF Bay Area
Posts: 484
JB NY,

What is your opinion on the use of surge tanks for water movement?


Carrera07 is offline   Reply With Quote
Old 07/15/2004, 09:43 AM   #6
rstark33
Registered Member

rstark33's Avatar

Join Date: Jan 2002
Location: Gresham, OR
Posts: 294
I have a question about flow based on experience from diving.
Cozumel has one of the best reefs in the world. The SPS is extremely thick and beautiful. The curent at Cozumel is nothing like what is described in the first post. It is a constant on directional current at a couple knots. It is like being in a constant strong wind. The dives are all drift dives and you can't swim against the current.
I guess my question is if I mimic the current affect in Cozumel why won' the SPS do well, or as well as the mixed changing current described above? Is this a case where we can improve on or pick the optimimum conditions in nature? Does anyone run a one directional current like in nature?


__________________
Rich

Current Tank Info: 90 Gallon with 100 gallon sump in garage
rstark33 is offline   Reply With Quote
Old 07/15/2004, 09:46 AM   #7
Bomber
10 & Over Club

Bomber's Avatar

Join Date: Sep 2000
Location: Florida Keys
Posts: 10,557
Quote:
Originally posted by Mark
Water flow shouldn't only be addressed by pumps and and other current generators. Two other big factors is live rock aquascaping and stocking densities. Poor rock placement has a huge impact on flow. This is obvious and advised by most reef books. But stocking density is the other big issue. It really doesn't matter how many Tunze streams you have if you try to crowd too many sps-corals together. They will quickly block each other off from incoming current. That is why some more experienced sps keepers get a little critical of densely stocked tanks full of frags and colonies. After having my share of RTN episodes and crashes, I've learned less is more. I think it's much easier to regulate flow in a tank with fewer but much larger colonies, than a tank with many colonies that are smaller and crowded.

Take JB's tank for example: as his coral have grown, he's removed some colonies to make room for the growth of other colonies(reading from other posts). I'm willing to bet that the remaining corals grew faster after the removal, by opening the coral up to more flow and light.
Exactly.

Eductors don't hurt either.


Bomber is offline   Reply With Quote
Old 07/15/2004, 12:11 PM   #8
westonm
Registered Member

Join Date: Dec 2001
Location: Milwaukee, WI
Posts: 75
rstark33,

With regards to Cozumel, my guess would be that those reefs are a very different sort of environment than the niche we commonly try to mimic. I remember mostly massive stonies at Cozumel that form huge mounds or globes (like a closed brain coral) mixed with many gorgonian and other life. I think the pacific sps corals we keep desire conditions more similar to the A. palmata (elkhorn) and A. cervicornis (staghorn) corals in the Carribean that grow best in the turbulent breakers or other areas with variable flow. Not sure if that is correct but it would be my guess.

Great thread idea JB NY

--Matt


westonm is offline   Reply With Quote
Old 07/15/2004, 01:14 PM   #9
prafferty
Moved On

prafferty's Avatar

Join Date: Mar 2003
Location: San Antonio, TX
Posts: 520
Just thinking outloud:
Why a Tunze then as it comes from one direction with the possibility of some obstacles. Wouldnt we all be better off with something like the ocaensmotions that can be set up coming from many different directions and intermitent if one chooses?


prafferty is offline   Reply With Quote
Old 07/15/2004, 01:31 PM   #10
Typhon
Force of Nature

Typhon's Avatar

Join Date: Feb 2003
Location: Charlotte, NC
Posts: 2,818
Very informative thread!!!

Flow was the most difficult part of setting up my reef tank. I spent a good amount of time engineering a system to prevent dead spots.

But even with a close going to a 4-way OM unit and MJ 1200. I still have a few small dead spots..


__________________
"If at first the idea is not absurd, then there is no hope for it."
- Albert Einstein

Current Tank Info: Tank Broken Down
Typhon is offline   Reply With Quote
Old 07/15/2004, 01:49 PM   #11
JB NY
Registered Member

JB NY's Avatar

Join Date: Mar 2001
Location: Long Island, NY
Posts: 9,225
schanz, I only have one stream in my tank. I mounted it on the side pointing down the long end of the tank near the front. It's really the only place I could fit it.

Quote:
Originally posted by Mark
Water flow shouldn't only be addressed by pumps and and other current generators. Two other big factors is live rock aquascaping and stocking densities. Poor rock placement has a huge impact on flow. This is obvious and advised by most reef books. But stocking density is the other big issue. It really doesn't matter how many Tunze streams you have if you try to crowd too many sps-corals together. They will quickly block each other off from incoming current.
Yup. I think it's one the biggest reasons people start to see problems in their tank after a few years. Keeping up with the changes in flow is tough. Even harder when you have lots of corals in tight areas.

Quote:
Originally posted by AI3
JB NY,

What is your opinion on the use of surge tanks for water movement?
I think they work pretty well. I've seen a few tanks with them. Personally I don't like them because of the size of the plumbing and extra tanks needed to get a surge as well as the bubbles and noise. But they work well, and some people really like them. It's another way of getting good water movement.

rstark33, There is so much current in a real reef. I don't think our small tanks can come close to the amount of flow in the wild. I think in our tanks we try to get as much as possible but there is really no way to get the kind of flow and turnover that a real reef has.

Bomber, I agree with you, eductors are superb at getting tons of flow in the tank. I can't use them as I have a DSB in my tank and it would kick up way too much sand.

prafferty, I think the oceanmotions are a great idea. But you need to plumb the whole thing up so it can be hard to put into an existing setup. But for new setups, I think they are very promising. Streams do move a ton of water though, more than I think you could realistically get out of an ocean motions unit. But each tank has needs that one or both of the product can help with, IMO.


__________________
-Joe

TOTM Sept 2002 | Reefland Featured Member April 2004
CORAL Magazine Oct/Nov Featured Tank 2007 | Featured Tank "Coral Reef Aquarium" 2011

Current Tank Info: 270G SPS Tank, 140G sumps, 35G Frag Tank, Ultra Reef Akula UKS-200 Skimmer, Apex, Giesemann Spectra 3x250W MH 4x80W T5, 2xReefbrite Tech 72" Blue LED, Triton Dosing, ARID C30 Algae Reactor, Maxspect Gyre
JB NY is offline   Reply With Quote
Old 07/16/2004, 10:05 AM   #12
agiacosa
Registered Member

agiacosa's Avatar

Join Date: Aug 2002
Location: Miami, FL
Posts: 973
Great thead JB, thanks.

I am planning my 58g's flow. I think I've decided to run a Calfo manifold return that will allow me to redirect return flow in the future to take into account SPS growth.

I will likely use a Wave2K center unit (the belt problem is fixed now) to create back and forth surge motion. If I feel I need more flow, I may add a single Stream on the floor or an over-the-back closed loop.

One thing I am doing with this project is factoring in LR placement and its impact on water movement. I will be using Tonga rock for its porosity and ability to limit how much touches the floor. I will also be using less than I've done in the past.

Of course, I'm going starboard bottom to maximize flow and cleanliness. May try that faux sand approach.


__________________
"Patience" is what most of us lack.
SPS = "Stability Promotes Success"
Slowly building a 60g Zeovit-run SPS reef

Current Tank Info: 60g SPS Reef
agiacosa is offline   Reply With Quote
Old 07/16/2004, 10:20 AM   #13
phishlipripper
Registered Member

phishlipripper's Avatar

Join Date: May 2003
Location: MI
Posts: 486
Great thread.

I am currently running 4 MJ1200's on a Red Sea Wavemaster Pro. It seemed like a whole lot of current initially but now that my tank has been maturing I can tell that the flow has been reduced.

There is also another problem, as my corals are growing they are starting to go into the direct streams of the MJ's which totally rips off all flesh from the skeleton. I can see this a huge problem in the near future. How are you guys that run MJ's solving this while still keeping your flow up?

All of my MJ's are near the top of my tank also.


__________________
"It is better to have and not need then to need and not have."

-P. H. Capstick

Current Tank Info: 75G AGA SPS and Clam dominant, 125G sump/prop tank, 3 250W DE (2 AB 10K, 1 Hammy 14K)+ 2-110W URI 03, 2-3/4" SeaSwirls 1 on Mag9.5, AIS Ca Rx and Media Rx, ES8-2, Sequence Barracuda return pump, Tunze 6100 and controller
phishlipripper is offline   Reply With Quote
Old 07/16/2004, 10:22 AM   #14
Mark
Premium Member

Mark's Avatar

Join Date: Oct 1999
Location: Atlanta, GA, USA
Posts: 4,552
phishlipripper,

If you cut the nozzles off on the MJ, the flow will be more distributed and less like a pressure washer. It's a common modification, just do a search on RC. HTH.


__________________
-Mark

TOTM March 2001

Current Tank Info: 225g stony reef, 38g softie
Mark is offline   Reply With Quote
Old 07/16/2004, 10:20 PM   #15
Zander
Registered Member

Zander's Avatar

Join Date: Mar 2002
Location: San Diego, CA
Posts: 688
Great thread. When talking about water flow, I think it is very important to differentiate between flow vs. velocity. For example, many think that just because the velocity is high, that they are getting a lot of flow (gph). This is a common misunderstanding that I have seen quite a bit.


Zander is offline   Reply With Quote
Old 07/16/2004, 11:55 PM   #16
clowntank10
Moved On

clowntank10's Avatar

Join Date: Mar 2004
Location: highland Clifornis
Posts: 631
OK NEWBIE QUESTION. im still in the process of settingup my 55g i still havnt decided when i return the water from the sump. scwd or a spray bar. here's a pic of the setup now.






i intend not to change this setup of rockwork. cause i'll give the fish more room to swim. tahts bout 40#'s live rock as of now i dont intend to add more but my mind canges like the clock


clowntank10 is offline   Reply With Quote
Old 07/17/2004, 12:10 AM   #17
G-money
Premium Member

G-money's Avatar

Join Date: Sep 2000
Location: Mpls, MN
Posts: 2,253
I've found that when using high volume pumps (closed loops, Streams), a great way to manage a lot of flow is to bank it off the glass. You lose some of the direct velocity, but it creates very random currents - you can get behind and under rocks in ways not possible with outputs blazing right over the rockwork. Of course this can play havoc with sandbeds, but... I don't have that issue.

I no longer use wavemakers, because I've found that I can get the same overall effect by doing this. The added benefit is that the pumps are always on, so a constant amount of water is always being moved, but the corals are not always getting blasted. FWIW...


__________________
I'll shut up now...

Current Tank Info: 120 reef, 75 plant
G-money is offline   Reply With Quote
Old 07/17/2004, 12:50 AM   #18
clowntank10
Moved On

clowntank10's Avatar

Join Date: Mar 2004
Location: highland Clifornis
Posts: 631
off the glass bang sounds crazy enough to work. great advice i'll use it. i see wher you rae coming from


clowntank10 is offline   Reply With Quote
Old 07/17/2004, 12:53 AM   #19
clowntank10
Moved On

clowntank10's Avatar

Join Date: Mar 2004
Location: highland Clifornis
Posts: 631
so still scwd, spraybar, or just the return line i'll use off the glass bangs with these but which one will be best.


clowntank10 is offline   Reply With Quote
Old 07/20/2004, 07:16 AM   #20
JB NY
Registered Member

JB NY's Avatar

Join Date: Mar 2001
Location: Long Island, NY
Posts: 9,225
Also wanted to point out my feeling that large staghorn acroporids do more harm than good in a tank. I think they grow too quickly and when large cut off flow to huge sections of the tank. Most of us would be better served with smaller more compact acros I think.


__________________
-Joe

TOTM Sept 2002 | Reefland Featured Member April 2004
CORAL Magazine Oct/Nov Featured Tank 2007 | Featured Tank "Coral Reef Aquarium" 2011

Current Tank Info: 270G SPS Tank, 140G sumps, 35G Frag Tank, Ultra Reef Akula UKS-200 Skimmer, Apex, Giesemann Spectra 3x250W MH 4x80W T5, 2xReefbrite Tech 72" Blue LED, Triton Dosing, ARID C30 Algae Reactor, Maxspect Gyre
JB NY is offline   Reply With Quote
Old 07/20/2004, 11:53 AM   #21
clowntank10
Moved On

clowntank10's Avatar

Join Date: Mar 2004
Location: highland Clifornis
Posts: 631
is there such thing as too much waterflow. cause my return pump is very strong. its blowing the sand back and etc. everything in the tank is moving fast. but after i stop the pump evrything stechess out very well. no sps in my tank yet. dont think its mature enough one more mopnth and ill hit 5 months so.... waiting then i'll get frags


clowntank10 is offline   Reply With Quote
Old 07/20/2004, 12:07 PM   #22
jackson6745
Yeah Yeah

jackson6745's Avatar

Join Date: Mar 2003
Location: Rockaway Park, NY
Posts: 5,826
Quote:
Originally posted by phishlipripper
How are you guys that run MJ's solving this while still keeping your flow up?

All of my MJ's are near the top of my tank also.
Change out the 4xMJ's for 2 Rio Seio 820's. Less heat, less electricity, same cost, more flow (more gentile too)


__________________
Richard - Officially done shipping coral. Don't ask!

http://www.reefcentral.com/forums/showthread.php?t=2357196"]http://www.reefcentralcom/forums/showthread.php?t=2357196
Officially Done Shipping

Last edited by jackson6745; 07/20/2004 at 12:19 PM.
jackson6745 is offline   Reply With Quote
Old 07/20/2004, 12:10 PM   #23
stealyourhouse
Premium Member

stealyourhouse's Avatar

Join Date: Apr 2002
Location: Ferguson, MO
Posts: 861
Bouncing the stream off of the glass is good for breaking up the stream of water, so that it isn't just one direct blast of water hitting the corals, but it doesn't eliminate the need for some type of alternating current device. The glass will break up the stream of water the same way all day as long as the pump is on. So even though your water may seem choppy from the top of your tank, it's a consistent choppiness.

I think that alternating current with some type of wavemaker is still absolutely necessary.


stealyourhouse is offline   Reply With Quote
Old 07/20/2004, 12:13 PM   #24
stealyourhouse
Premium Member

stealyourhouse's Avatar

Join Date: Apr 2002
Location: Ferguson, MO
Posts: 861
clowntank10,

There isn't really a way to get too much flow in a reef tank. What's important though is that you don't want direct flow from a pump or powerhead hitting your corals, or it will tear the flesh right off.


stealyourhouse is offline   Reply With Quote
Old 07/20/2004, 12:18 PM   #25
TurboRook
Registered Member

TurboRook's Avatar

Join Date: Jun 2001
Location: South Pasadena, CA
Posts: 190
When it comes to an SPS dominated tank, it is hard to have too much total flow. There are two limiting factors, though:

1) Sandstorms - sugar-fine sand becomes a real limiting factor in SPS tanks, especially as they mature and grow out. There is only so much flow you can get before you create a permanent sandstorm. This can be especially problematic in tanks with multiple colonies in the lower half of the water column and when you need to increase flow to prevent lower branch recession.

2) Velocity - the nozzle velocity of powerheads and plumbing outlets can also be a llimiting factor. As has been said before, high velocities can literally tear tissue right off a branch. To reduce this, use larger plumbing fittings for the outlets, eductors, and high-flow powerheads such as Streams and Seios.


__________________
Mike

Current Tank Info: 80g stony
TurboRook is offline   Reply With Quote
Reply

Thread Tools

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is On

Forum Jump


All times are GMT -6. The time now is 08:45 AM.


TapaTalk Enabled

Powered by vBulletin® Version 3.8.4
Copyright ©2000 - 2017, Jelsoft Enterprises Ltd.
Powered by Searchlight © 2017 Axivo Inc.
Use of this web site is subject to the terms and conditions described in the user agreement.
Reef CentralTM Reef Central, LLC. Copyright 1999-2014
